Dimensions and Parameters |
Overall Dimension(L x W x H) |
11120x2540x3935mm |
|
Wheelbase: |
5820+1370mm |
|
|
Front Wheel Distance: |
2065mm |
|
|
Rear Wheel Distance: |
1855/1855mm |
|
|
Front/Rear Suspension |
1370/2950mm |
|
|
Approach/Departure angle: |
17/18° |
|
|
Leaf Spring: |
8/10 |
|
|
Weights and Capacities |
Curb Weight: |
17580kg |
|
Payload: |
15290kg |
|
|
GVW: |
33000kg |
|
|
Axle Loads: |
7000/26000/26000kg |
|
|
Engine |
Engine Model: |
6UZ1-TCG51 |
|
Max output: |
279Kw |
|
|
Displacement: |
9839ml |
|
|
Horsepower: |
380Ps |
|
|
Exhaust Gas Treatment Technology： |
SCR |
|
|
Transmission |
Transmission: |
ZF8S2230TO |
|
Forward Gear: |
8 Speed Gear |
|
|
Backward Gear: |
1 Speed Gear |
|
|
Brake |
Air Brake |
|
|
Front Drum Back Drum |
||
|
With Exhaust Brake |
||
|
Generator |
24V-120A |
|
|
Cab |
Number of Seats: |
2 |
|
Cabin Type: |
Standard Roof One Bed |
|
|
Chassis |
Drive Type: |
6x4 |
|
Tires: |
11(Including Spare Tire) |
|
|
Tire Model: |
315/80R22.5-18PR |
|
|
Fuel Tank |
Number: |
1 |
|
Capacity: |
400L |
|
|
Configurations: |
1 |
Power Steering System |
|
2 |
Air Conditioning |
|
|
3 |
Central Lock |
|
|
4 |
Power Window |
|
|
5 |
Driving Data Recorder |
|
|
6 |
Tubeless Tire |
|
|
7 |
ABS |
|
|
8 |
Free Maintenance Battery |
|
|
9 |
Front Chrome Kit |
|
|
10 |
Aluminum alloy gas tank |
|
|
11 |
Air Suspension Cabin |
|
|
12 |
Air suspension Seat |
|
|
Top Parameters |
Pressure-Vacuum Tank Volume |
9000L |
|
Clean Water Tank Volume |
5000L |
|
