Overall Dimension: L*W*H |
8270×2550×3480mm |
|
|
Cabin Crew |
2+4 |
|
|
Water Tank |
Water/Foam tank volume |
Water 8000kg |
|
Material |
stainless steel 304 |
|
|
Fire Pump |
Main performance |
When pressure is 1.0MPa, flow is 60L/s When pressure is 2.0Mpa, flow is 30L/s |
|
Water diversion time |
<=35s |
|
|
Fire Monitor |
Rated Flow |
50L/S |
|
Work pressure |
0.8MPa |
|
|
Shooting range |
70m |
|
|
Horizontal rotation angle |
360° |
|
|
Back leaning Angle： |
-10～80° |
|
